Mikroskopi > Mikroskop > Upprättstående mikroskop > Ljusfältsmikroskop > Euromex > iScope > Euromex Mikroskop iScope IS.1153-EPL, trino
Artikelnr: 51449

Mikroskop iScope IS.1153-EPL, trino

på kort sikt
leveransklar om 3-5 veckor + Frakttid

Beskrivning av artikel

Tyvärr har den här beskrivningen ännu inte översatts till svenska, så du hittar en engelsk artikelbeskrivning här.

Euromex introduces a complete new series of iScope® microscopes. These state-of-the-art instruments have been specifically designed for Life Sciences and Biomedical Sciences.

The iScope® is available in different configurations. Thanks to the high resolving power of the objectives and the 3W NeoLed transmitted LED illumination, these microscopes can be used for all kind of demanding applications as well for fundamental research. Please find below a summary of the specifications

  • EWF10x/22 mm or EWF10x/20mm eyepieces
  • Binocular and trinocular heads
  • Quintuple nosepiece
  • E-Plan EPL 4x/0.10, 10x/0.25, 20x/0.40, S40x/0.65, S100x/1.25 oil-immersion DIN objectives
  • E-Plan EPL IOS 4x/0.10, 10x/0.25, 20x/0.40, S40x/0.65, S100x/1.25 oil-immersion IOS objectives
  • Plan PL IOS 4x/0.10, 10x/0.25, 20x/0.40, S40x/0.65, S100x/1.25 oil-immersion IOS objectives
  • 140 mm x 160 mm stage equipped with integrated 79 x 52 mm mechanical stage
  • 216 mm x 150 mm rackless stage equipped with integrated 79 x 52 mm mechanical stage
  • Height adjustable Abbe condenser N.A. 1.25
  • Coarse and fine height adjustment
  • Diascopic intensity adjustable 3W NeoLED™ illumination with internal 85V-240V power supply
  • iCare sensor for energy saving
  • CSS - Cable Storage System

  • Models IS.1152-EPL and IS.1153-EPL are supplied with E-Plan objectives for bright field applications
  • Models IS.1152-EPLi and IS.1153-EPLi are supplied with E-Plan IOS objectives for bright field applications
  • Models IS.1152-PLi and IS.1153-PLi are supplied with Plan IOS objectives for bright field applications

The iScope is also available in a multi-head configuration

Euromex iScope for brightfield IS.1153-EPL

  • Eyepieces EWF10x/20 mm
  • Head Trinocular version with Siedentopf 30° inclined tubes. Interpupillary distance 47-76 mm with diopter adjustment on left eyepiece
  • Nosepiece Revolving quintuple reversed nosepiece on ball bearings
  • Objectives E-Plan EPL 4x/0.10, 10x/0.25, S40x/0.65, S100x/1.25 oil-immersion DIN objectives. All optical parts are anti-fungus treated
  • Stage 140 mm x 160 mm stage equipped with integrated 79 x 52 mm mechanical stage
  • Condenser In height adjustable Abbe N.A. 1.25 condenser with opening for optional sliders
  • Focusing adjustment Coaxial coarse and fine adjustments, 2 µm precision, 20 mm travel range. Rack-stop for protection of slides and objectives. Friction adjustment
  • Illumination and power supply Diascopic intensity adjustable 3W NeoLED™ illumination with internal 100V-240V power supply (CE)
  • iCare Sensor The unique iCare Sensor is developed to avoid unnecessary loss of energy. The illumination of the microscope automatically switches off when the microscopist steps away from his position
  • CSS - Cable Storage System The Cable Storage System of the iScope allows the user to practically insert the power cable into the backside of the instrument, which enables easy storage
  • Packaging Delivered with power cord, 500 mA 250V spare fuse and dust cover

Tekniska data

Optik


Belysning
Transmitterat ljus
Lamptyp
LED
Fältkurvatur
plan
Färgkorrigering
akromatisk
Okular
EWF 10x / 20 mm
Antal objektiv
4
Objektiv 1
4x / 0.10
Objektiv 2
10x / 0.25
Objektiv 3
S40x / 0.65
Objektiv 4
S100x / 1.25
Fjädring
ja
Immersionsobjektiv
ja
Kondensor
Abbe 1,25 N.A. fokuserbar med irisbländare
Oändligt korrigerad
nej
Förstoring
40 - 1000
Optiskt system
DIN (160mm)

Prestanda


Ljusfält
ja

Mekanik


Typ av byggnad
Trinokulärt mikroskop
Fokusering
Grov- och fininställning (200 x 1µm)
Objektbord
Korsbord (140 x 160mm (x/y 79 x 52mm))
Revolver
5

Allmänt


Serie
iScope
Vikt (g)
9000
Bredd (mm)
210
Längd (mm)
255
Höjd (mm)
407

Övrigt


Leverantörens produktnummer
IS.1153-EP
